UPVC SYSTEMS

PVC sliding systems offer better arrangement possibilities by saving space and providing the outstanding option of seamlessly connecting rooms. They can be used to connect a living room with the garden or a flat with a terrace so that the space is unobstructed by protruding thresholds. These systems are so easy to use, especially in HST options, that anyone can use them, and their performance is good enough to complement passive buildings.

Patio

basic sliding door system

  • micro-ventilation in the corner of the active sash as standard

Easy Slide ST60

1-2 Guilding Rails profile with a construction depth of 2"-3/8" (60 mm)

  • overall glazing thickness up to 13/16" (20 mm)

Multi Slide ST80

2-3 Guilding Rails overall glazing thickness up to 1-5/16" (33 mm)

  • maximum size for construction – H up to 86-5/8" (2200 mm) , L up to 126" (3200 mm)

Smart Slide

1-2 Guilding Rails profile with a construction depth of 5-1/2" (140 mm)

  • overall glazing thickness up to 1-5/8" (42 mm)

HST 85

profile with a construction depth of 7-3/4" (197 mm)

  • maximum sash weight: 881 lb

EvolutionDrive 82

1-2 Guilding Rails profile with a construction depth of 194 mm

  • glazing with glass units up to 52 mm

American Sliding Patio Door

5 ⅕” installation depth ~3/4" double glazing units externally glazed

  • integrated nailing fin for streamlined installation in new construction

evolutionDrive Plus+

1 Guilding Rails glazing with packages up to 49 mm wide

  • maximum dimensions of the fix sash (HxL) – 2480 x 4000 mm
